Features
|
179
|
177
|
175
|
|
Max voltage
|
1000
|
1000
|
1000
|
|
True-rms
|
o
|
o
|
o
|
|
Temperature
|
o
|
|
|
|
Basic dc accuracy
|
0.09%
|
0.09%
|
0.09%
|
|
Backlight
|
o
|
o
|
|
|
Min/Max/Avg
|
o
|
o
|
o
|
|
사이버 견적 담기
|
|
|
|
|
Functions
|
Range and Resolution
|
Basic accuracy
|
|
DC voltage
|
600.0mV, 6.000V, 60.00V, 600.0V, 1000V
|
±0.09%(Models 177 anc 179)
±0.15%(Model 175)
|
|
AC voltage1
|
600.0mV, 6.000V, 60.00V, 600.0V, 1000V
|
±1.0% of reading
|
|
DC current
|
60.00mA, 400.0mA, 6.000A, 10.00A2
|
±1.0% of reading
|
|
AC current
|
60.00mA, 400.0mA, 6.000A, 10.00A2
|
±1.5% of reading
|
|
Resistance
|
600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, 6.000MΩ, 50.00MΩ
|
±0.9% of reading
|
|
Capacitance
|
1000nF, 10.00µF, 100.0µF, 9999µF
|
±1.2% of reading
|
|
Frequency3
|
99.99Hz, 999.9Hz, 9.999Hz, 99.99kHz
|
±0.1% of reading
|
|
Temperature(Model 179)
|
-40℃ to +400℃ (-40℉to +752℉)
|
1.0% of reading
|
|
1All ac voltage and ac current ranges are specified from 5% of range to 100% of range
210A continuous, 20A for up to 30 seconds
3Voltage frequency is specified from 2Hz to 100kHz. Current Frequency is specified from 2Hz to 30kHz.
|
|
|
|
Model
|
Description
|
사이버 견적 담기
|
|
C25
|
Large Soft Case for DMMs
|
|
|
C100
|
Universal Carrying Case
|
|
|
i2000 flex
|
AC Current Clamp
|
|
|
i410
|
400A AC/DC Current Clamp
|
|
|
80K-15
|
High Voltage Probe
|
|
|
80K-40
|
High Voltage Probe
|
|
|
80K-6
|
High Voltage Probe
|
|
|
80AK-A
|
Thermocouple Adapter
|
|
|
80BK-A
|
Integrated DMM Temperature Probe
|
|
|
80PK-1
|
High Voltage Probe
|
|
|
80PK-26
|
Tapered Temperature Probe
|
|
|
80PK-11
|
Thermocouple Temperature Probe
|
|
|
80T-150UA
|
Universal Temperature Probe(for DMMs)
|
|
|
| |
|
|
|
