Features
|
8845A
|
8846A
|
|
Dudal VFD dot matrix display
| o
|
o
|
|
6.5 digit resolution
|
o
|
o
|
|
Continuity/diode test
|
o
|
o
|
|
Statistics, Histogram, TrendPlot, Limit Test analytical functions
|
o
|
|
|
Zero, Min/Max/Average, Std Dev; mx +b, dB/dBm math functions
|
o
|
o
|
|
USB memory drive port
|
|
o
|
|
Real-time clock
|
|
o
|
|
RS-232, IEEE-488.2, Ethernet, USB (with optional adapter)
|
o
|
o
|
|
SCPI(IEEE-488.2), Agilent 34401A, Fluke 45 programming languages/emulation modes
|
o
|
o
|
|
Complies with IEC 61010-2000-1, ANSI/ISA-S82.01-1994, CAN/CSA-C22.2 No. 61010.1, 1000V CAT 8/600 V CAT II
|
o
|
o
|
|
사이버 견적 담기
|
|
|
|
Functions
|
8845A
|
8846A
|
|
Range
|
Resolution
|
Accuracy* (%)
|
Range
|
Resolution
|
Accuracy* (%)
|
|
Voltage dc
|
1000V
|
100ns
|
0.0035
|
1000V
|
100ns
|
0.0024
|
|
Voltage ac (freq. 300kHz)
|
750V
|
100ns
|
0.06
|
1000V
|
100ns
|
0.06
|
|
Resistance (2x4 wire)
|
100M
|
100µ
|
0.01
|
1G
|
10µ
|
0.01
|
|
Current dc
|
10A
|
100pA
|
0.05
|
10A
|
100pA
|
0.05
|
|
Current ac (freq. 3Hz to 10kHz)
|
10A
|
1µA
|
0.10
|
10A
|
10nA
|
0.10
|
|
Freq/period
|
300kHz
|
1µHz
|
0.01
|
1MHz
|
1µHz
|
0.01
|
|
Capacitance
|
|
|
|
1nF to 0.1F
|
1pF
|
1
|
|
Temperature RTD
|
|
|
|
-200℃ to +600℃
|
0.001 °
|
0.06 °
|
|
*Accuracy = ±(% of reading)
|
|
|
|
Model
|
Description
|
|
TL71
|
Test Lead Set
|
|
TL710
|
Electronic Test Probes
|
|
TL2x4W-PTII
|
2x4-Wire Ohms Test Lead
|
|
TL2x4W-TWZ
|
2x4-Wire Ohms Tweezers Test Lead
|
|
8845A-EEPT
|
Extended Fine Point Tip Adapter Set (red and black)
|
|
8845A-TPIT
|
Test Probe IC Tip Set (red and black)
|
|
884X-RTD
|
100 Ohm RTD Temperature Probe
|
|
TL80A
|
Basic Electronic Test Lead Set
|
|
884X-SHORT
|
4-Wire Short
|
|
884x-CASE
|
Molded plastic case
|
|
Y8846D
|
Rack Mount Kit, Dual
|
|
Y8846S
|
Rack Mount Kit, Single
|
|
884X-ETH
|
Ethernet Interface Cable
|
|
884X-USB
|
USB to RS232 Cable Adapter
|
|
RS43
|
RS-232 Cable (RS43, 2 m)
|
|
Y8021
|
IEEE-488 cable (1 m)
|
|
Y8022
|
IEEE488 cable (2m)
|
|
FVF-SC4
|
FlukeView Forms with Cable for 8845/8846
|
|
| |
|
|
|
