제품정보 (메이커/스펙/옵션/액세서리/장비상태 등) |
6000 Micromanipulator Probe Station Factory Refurbished
Permanently planarized stage & vacuum chuck Coarse & Fine stage translation controls X & Y Fine & Fast Lift platen controls in Z Independent microscope lift Compound Microscope
Description Micromanipulator’s 6000 series is the most widely used probe station by any manufacturer. Compatible with Micromanipulator’s extensive line of probes and accessories, the 6000 series is very compact and economical making it an excellent foundation on which to build a complete probing system. This station is designed for the ease of use, stability and precision that you expect from a Micromanipulator probe station. The Model 6000 station has both coarse and fine X-Y stage controls which allow the user to quickly move across the wafer but also precisely position the sample for exact probing. The fast pull-out stage with vacuum lock allows for fast and easy access to the chuck to load and unload samples. The 1” x 1” x 2” (25mm x 25mm x 50mm) X-Y-Z microscope controls allow the user to view device structures and place widely placed probes under high magnification without moving the sample. The microscope may be mounted in a number of heights to accommodate structures of varying height. This 6000 has a compound microscope for high magnification of small wafer structures.
|
