R4131D Advantest Spectrum Analyzer
The R4131D is a 3.5 GHz Spectrum Analyzer from Advantest. A spectrum analyzer measures the power of spectrums of known and unknown signals. Spectrum analyzers collect information such as the magnitude of an input signal compared to its frequency. As a frequency analyzer, spectrum analyzers’ main use is to document and analyze electrical input signals as well as spectral compositions of other signals.
Frequency Range: 10 kHz - 3.5 GHz
Dynamic Range: -116dBm - +20dBm
Input Impeadance: 50 ohms
Resolution Bandwidth: 1 kHz - 1 MHz
Video Bandwidth: 10 Hz - 1 MHz
Residual FM: -80dBc
The Advantest R4131D has a measurement-condition memory function which includes waveforms, an auto-recall function which recalls measurement conditions when power is switched on and other features to simplify operation. The R4131D features a maximum input sensitivity of -116 dBm, a dynamic range of 70dB and a skirt characteristics of -80dBc or better.
