Inputs
Piezoelectric
Single-ended with one side connected to signal ground
Maximum charge input
≤ 10 000 pC
Source resistance
> 10 Meg ohms
Source capacitance
< 30 000 pF
Isotron
Single-ended with low side connected to signal ground
Constant excitation current
Off, 4 mA or 10 mA, one range is valid for all 3 channels selectable through front panel or RS-232
Accuracy
± 15%
Compliance voltage
< 22 VDC
Maximum input voltage
< 22 Volts (AC + DC components)
Input impedance
100 M ohms and 33 000 pF
Outputs
AC voltage
Single ended with one side connected to output signal ground. Signal proportional to input.
Maximum linear output
10 Vpk minimum
Display non-linearity
Inherent error 1% of full scale reading Inherent error 1% of full scale reading
Maximum current output
10 mA (10 V into a 1 k ohms load)
DC offset
15 mV maximum
Protection
Short circuit protected
|
